Item #

Rated Load

Thread Size

Thread Protrusion (E)

B

Torque

43585

3050 kg

M24 x 3.00

47 mm

3 3/4 in

80 ft/lb

43590

4850 kg

M30 x 3.50

44 mm

4 5/8 in

150 ft/lb

43580

2290 kg

M20 x 2.50

40 mm

3 3/4 in

50 ft/lb

43605

11300 kg

M48 x 5.00

95 mm

4 5/8 in

300 ft/lb

43570

725 kg

M12 x 1.75

24 mm

2 3/8 in

15 ft/lb

43575

1400 kg

M16 x 2.00

31 mm

2 3/8 in

25 ft/lb

43565

500 kg

M10 x 1.50

20 mm

1 1/2 in

4.5 ft/lb

43600

8200 kg

M42 x 4.50

84 mm

4 5/8 in

250 ft/lb

43595

7700 kg

M36 x 4.00

63 mm

4 5/8 in

250 ft/lb

43560

325 kg

M8 x 1.25

16 mm

1 1/2 in

3.5 ft/lb
